INTAKE EXHAUST VALVE SEAL SPRING & VALVE GUIDES KIT 1996-2014 HONDA TRX400 XR400R

This intake and exhaust valve seal, spring, and guide kit is engineered to OEM specifications for reliable valvetrain refurbishment, providing matched components for correct fit, function, and service life.

Features

• Unmatched reliability and performance from high-tech materials
• Manufactured to exacting standards so the engine can be rebuilt with total confidence
• Meets or exceeds OEM quality
• Direct OEM replacement
• Please see image before ordering to avoid mistakes
• Best value for money
• High-quality replacement parts
• Easy to install; if unsure, please use a professional

Specifications

• Kit contents: valve stem seals, valve cotters, tappet adjusting screw, inner valve springs, valve spring retainers, outer valve spring seats, intake valve, exhaust valve, valve guides, O-ring (10 × 1.6)

Cross-Reference OEM Part Numbers

• 12209-KL4-005 – Seal, valve stem
• 14781-HA0-770 – Cotter, valve
• 90012-MG3-000 – Screw, tappet adjusting
• 14761-KG0-003 – Spring, valve (inner)
• 14771-107-020 – Retainer, valve spring
• 14775-KCY-670 – Seat, valve spring (outer)
• 14711-KCY-670 – Valve, intake
• 14721-KCY-670 – Valve, exhaust
• 12231-KF0-305 – Guide, valve
• 91301-200-000 – O-ring (10 × 1.6)

Vehicle Fitments

• 1999 Sportrax 400 TRX400EX 2×4
• 2000 Sportrax 400 TRX400EX 2×4
• 2001 Sportrax 400 TRX400EX 2×4
• 2002 Sportrax 400 TRX400EX 2×4
• 2003 Sportrax 400 TRX400EX 2×4
• 2004 Sportrax 400 TRX400EX 2×4
• 2005 Sportrax 400 TRX400EX 2×4
• 2006 Sportrax 400 TRX400EX 2×4
• 2007 Sportrax 400 TRX400EX 2×4
• 2008 Sportrax 400 TRX400EX 2×4
• 2009 TRX400X 2×4
• 2012 TRX400X 2×4
• 2013 TRX400X 2×4
• 2014 TRX400X 2×4
• 1996 XR400R
• 1997 XR400R
• 1998 XR400R
• 1999 XR400R
• 2000 XR400R
• 2001 XR400R
• 2002 XR400R
• 2003 XR400R
• 2004 XR400R
