CYLINDER KIT 96.00mm STD 2020-2025 HONDA TRX 520 12100-HR6-B00

A complete cylinder, piston and gasket top-end rebuild kit with a standard 96.00 mm bore for Honda 518 cc single-cylinder engines. Designed as a direct replacement for the original components on TRX520 (Foreman and Foreman Rubicon) ATVs and Pioneer 520 UTVs, maintaining the OEM bore × stroke (96.0 mm × 71.5 mm) and 19 mm wrist-pin size.

Features

• Standard 96.00 mm bore to maintain the 518 cc displacement with a 71.5 mm stroke
• Direct replacement dimensions for OEM components
• Manufactured to precise tolerances for dependable performance
• Aluminium construction
• 19 mm piston pin with circlips included
• Supplied with cylinder head, base and head-cover gaskets
• Visual check of the product images before ordering is recommended
• Straightforward to install; professional fitting is advised if unsure
• Part numbers supplied for identification and cross-reference only

Specifications

• Material: Aluminium
• Displacement: 518 cc
• Bore type: Standard
• Bore diameter: 96.00 mm
• Stroke: 71.5 mm
• Piston pin diameter: 19 mm
• Included in set: Cylinder; piston; piston ring set; wrist pin; 2 × piston circlips; cylinder head gasket; cylinder base gasket; cylinder head cover gasket

Cross-Reference OEM Part Numbers

• Cylinder: 12100-HR6-B00
• Cylinder Base Gasket: 12191-HR6-B01
• Cylinder Head Gasket: 12251-HR6-B01
• Cylinder Head Cover Gasket: 12315-HR0-F01
• Piston (Std): 13101-HR6-B00
• Pin, Piston: 13111-HP5-600
• Piston Ring Set (Std): 13010-HR6-305
• Circlips, piston (2): 13112-MAT-000

Vehicle Fitments

• Honda FourTrax Foreman 520 TRX520FE2 4x4 ES EPS: 2020–2025
• Honda FourTrax Foreman 520 TRX520FM1 4x4: 2020–2025
• Honda FourTrax Foreman 520 TRX520FM2 4x4 EPS: 2020–2025
• Honda FourTrax Foreman Rubicon 520 TRX520FA5 4x4 Auto DCT: 2021–2024
• Honda FourTrax Foreman Rubicon 520 TRX520FA6 4x4 Auto DCT EPS: 2021–2024
• Honda FourTrax Foreman Rubicon 520 TRX520FA7 4x4 Auto DCT EPS Deluxe: 2021–2024
• Honda FourTrax Foreman Rubicon 520 TRX520FM6 4x4 EPS: 2020–2024
• Honda Pioneer 520 SXS520M: 2021–2025
• Honda Pioneer 520 SXS520M2: 2021–2025
