Hot Rods Connecting Rod 04-05 TRX450R, Hotrod 8632

Hot Rods Connecting Rod 04-05 TRX450R, Hotrod 8632. Find the product specifications and compatibility information below.

Product details

• Product: Connecting Rod 04-05 TRX450R, Hotrod 8632
• Part number: 56-231.HR
• Brand: Hot Rods
• Manufactured from hot-rolled ASTM 4115 and case-hardened to 58-62 Rc.
• Strategically located side scalloping and vent slots minimize high-rpm bearing race distortion.
• Double-forged for improved grain flow and dimensional consistency.
• Shot-peened and double-honed for superior strength and durability.
• Small ends are double drilled for extra lubrication and cooling of the wrist pin bearing.
• Thrust washers and crank pin bearings are silver-coated for enhanced lubricity.
• Includes all components for a complete installation.
• Included Items:
• Rod
• Crank pin
• Crank pin bearing
• Top-end bearing
• Thrust washers
• Technical Specifications:
• Big End Bearing (mm): 35x46x23.2
• Big End Bore (mm): 46.00
• Big End Width (mm): 23.50
• Center-to-Center Length (mm): 111.40
• Cross-Reference OEM Part Numbers:

Vehicle fitment

Applications listed in the supplier fitment data:

• HONDA TRX R 450cc — 2004–2005
• HONDA TRX ER 450cc — 2004–2005

Match your exact make, model, year and specification before ordering.
