Hot Rods Connecting Rod 08-09 TRX700XX, Hot Rod 8679 Honda

Hot Rods Connecting Rod 08-09 TRX700XX, Hot Rod 8679 Honda. Find the product specifications and compatibility information below.

Product details

• Product: Connecting Rod 08-09 TRX700XX, Hot Rod 8679 Honda
• Part number: 56-856.HR
• Brand: Hot Rods
• Includes rod, crank pin, crank pin bearing, top-end bearing, and thrust washers.
• Manufactured from hot-rolled ASTM 4115 steel and case-hardened to 58–62 Rc for exceptional strength.
• Advanced design minimizes high RPM bearing race distortion with strategically located side scalloping and vent slots.
• Double-forged rods improve grain flow and dimensional consistency.
• Shot-peened and double-honed rods for superior strength under heavy loads.
• Small ends are double-drilled for improved lubrication and cooling to the wrist pin bearing.
• Thrust washers and crank pin bearings are silver-coated for added lubricity and durability.
• Technical Specifications:
• Big End Bore (mm): 50.00
• Big End Width (mm): N/A
• Center to Center (mm): 133.00
• Pin Diameter (mm): 38.00
• Pin Length (mm): 65.10
• Small End Bore (mm): 24.00
• Small End Width (mm): N/A
• Washer Thickness (mm): 1.00
• Cross-Reference OEM Part Numbers:
• Hot Rods HR008679
• Part Number: 56-856.HR

Vehicle fitment

Applications listed in the supplier fitment data:

• HONDA TRX XX 700cc — 2008–2009

Match your exact make, model, year and specification before ordering.
