Connecting Rod Kit 88-96 RM125, Psychic MX-09052 Suzuki

Connecting Rod Kit 88-96 RM125, Psychic MX-09052 Suzuki. Find the product specifications and compatibility information below.

Product details

• Product: Connecting Rod Kit 88-96 RM125, Psychic MX-09052 Suzuki
• Part number: 56-924.DR
• Brand: Psychic
• Heavy-duty connecting rod designed as an OE replacement.
• Constructed from certified chrome alloy steel for superior strength.
• Crankpins are hot-rolled ASTM steel and case-hardened for durability.
• Utilizes advanced caged needle roller bearing designs for high rpm performance.
• Thrust washers made from bronze phosphor with a silver coating.
• Complete assembly includes rod, crankpin, crankpin bearing, top-end bearing, and thrust washers if required.
• Fully compatible with aftermarket and OE crankshafts.
• Material: SNCM220
• Centre-to-Centre: 105 mm
• Small End Bearing: 15x19x19.80 mm
• Small End Bore Ø: 19 mm
• Small End Width: 18 mm
• Big End Bearing: 22x28x15.8 mm
• Big End Bore Ø: 28 mm
• Big End Width: 16 mm
• Big End Pin Ø: 22 mm
• Big End Pin Length: 53 mm
• Washer Thickness: 1.0 mm
• Cross Reference OEM Part Numbers
• Hotrods 8110
• ProX 03-3207
• Wossner P2015

Vehicle fitment

Applications listed in the supplier fitment data:

• SUZUKI RM 125cc — 1987
• SUZUKI RM 125cc — 1988–1996
• SUZUKI RM 125cc — 1987–1996

Match your exact make, model, year and specification before ordering.
