Connecting Rod 85-87 CR125

Connecting Rod 85-87 CR125. Find the product specifications and compatibility information below.

Product details

• Product: Connecting Rod 85-87 CR125
• Part number: 56-930.DR
• CR125R 1985-1987,
• CONNECTING CONROD ROD REBUILD KIT. PSYCHIC MX-09003
• Heavy-duty OE replacement connecting rods.
• Certified Chorme alloy steel provides superior strength.
• Crankpins are manufactured from hot-rolled ASTM steel and case hardened.
• Psychic Rods uses the latest in caged needle roller bearing designs for high rpm longevity.
• Thrust washers are manufactured from bronze phosphor and are silver coated.
• Rod assembly sold complete with rod, crankpin, crankpin bearing, top end bearing and thrust washers if need.
• Fully Compatible with after market and OE crankshafts.
• Material SNCM220,
• SIZE
• MM
• Centre 2 Centre
• 104
• Small End Bearing
• 14x19x18.7
• Small End Bore Ø
• 19
• Small End Width
• 16
• Big End Bearing
• 22x28x16
• Big End Bore Ø
• 28
• Big End Width
• Big End Pin Ø
• 22
• Big End Pin Length
• 53.80
• Washer Thickness
• 22x37x1.0
• Part No. 56-930.DR (www.fdyperformance.com)

Vehicle fitment

Applications listed in the supplier fitment data:

• HONDA CR 125cc — 1985–1987

Match your exact make, model, year and specification before ordering.
