Piston Kit KTM 520 525 Exc SX, Wossner 8637DC KTM 00-09 Hc

Piston Kit KTM 520 525 Exc SX, Wossner 8637DC KTM 00-09 Hc. Find the product specifications and compatibility information below.

Product details

• Product: Piston Kit KTM 520 525 Exc SX, Wossner 8637DC KTM 00-09 Hc
• Part number: 56-W216+00C.WO
• Brand: Wossner
• Piston Kit 95.02mm Bore 94.97 Wossner 8637DC (+0.02)
• Wossner forged pistons are superior in strength and design. Engineered to provide the best possible path for combustion chamber heat transfer to cylinder walls. Elliptically designed to provide a more uniform bearing surface under piston heat expansion, eliminating localized pressure and distributing thrust loads more evenly, thereby preventing piston collapse. Made in Germany.
• Lock P/N: CW20
• Pin P/N: WP029
• Ring Set P/N: 950ADS-2
• Display (cm3): 510
• Hub Stroke (mm): 72.00
• Clearance (mm): 0.05
• Wossner Compression Ratio: 12.50:1
• OEM Compression Ratio: 11.00:1
• Dome Volume (cm3): +4.60
• Compression Height (mm): 23.50
• Theoretical Weight (G):

Vehicle fitment

Applications listed in the supplier fitment data:

• KTM SX 520cc — 2000–2002
• KTM EXC 520cc — 2000–2002
• KTM SM R 525cc — 2004–2005
• KTM EXC 525cc — 2003–2007
• BETA RR 525cc — 2005–2009
• KTM SX 525cc — 2003–2007
• KTM EXC 525cc — 2003–2010
• KTM SX 525cc — 2003–2010

Match your exact make, model, year and specification before ordering.
