Piston Kit 07-09 RMZ250 Hc 77, Forged Wossner 8672DA 12111-10H20-0F0

Piston Kit 07-09 RMZ250 Hc 77, Forged Wossner 8672DA 12111-10H20-0F0. Find the product specifications and compatibility information below.

Product details

• Product: Piston Kit 07-09 RMZ250 Hc 77, Forged Wossner 8672DA 12111-10H20-0F0
• Part number: 56-W305.A.WO
• Brand: Wossner
• High-compression forged piston for increased performance
• Optimized heat transfer for improved efficiency
• Elliptical design ensures uniform bearing surface under heat expansion
• Even thrust load distribution to prevent piston collapse
• Manufactured in Germany
• Bore Size: 77mm (76.96mm)
• Compression Ratio: 13.9:1
• Part Number: 8672DA
• Lock Part Number: CW16
• Pin Part Number: WP070
• Ring Set Part Number: 770XAS-2
• Rod Part Number: P4004
• Displacement: 249 cm³
• Stroke: 53.60mm
• Clearance: 0.04mm
• OEM Compression Ratio: 13.4:1
• Dome Volume: -2.50 cm³
• Compression Height: 19.60mm
• Cross-Reference OEM Part Numbers
• 12111-10H20-0F0
• 4928M07700

Vehicle fitment

Applications listed in the supplier fitment data:

• SUZUKI RM Z 250cc — 2007–2009

Match your exact make, model, year and specification before ordering.
