Piston Kit KTM505SX-F Hc 100, Wossner 8725DB 08-09

Piston Kit KTM505SX-F Hc 100, Wossner 8725DB 08-09. Find the product specifications and compatibility information below.

Product details

• Product: Piston Kit KTM505SX-F Hc 100, Wossner 8725DB 08-09
• Part number: 56-W315+00B.WO
• Brand: Wossner
• High-compression forged piston for increased performance
• Optimized heat transfer for enhanced durability
• Elliptical design ensures uniform bearing surface under heat expansion
• Even thrust load distribution to prevent piston collapse
• Manufactured in Germany
• Bore Size: 100.01mm (99.96mm)
• Compression Ratio: 13.5:1
• Part Number: 8725DB
• Lock Part Number: CW20
• Pin Part Number: WP038
• Ring Set Part Number: 1000ADS-2
• Displacement: 449 cm³
• Stroke: 60.80mm
• Clearance: 0.05mm
• OEM Compression Ratio: 12.5:1
• Dome Volume: +0.30 cm³
• Compression Height: 21.80mm

Vehicle fitment

Applications listed in the supplier fitment data:

• KTM SX F 505cc — 2008–2009
• KTM SX F 505cc — 2007–2008

Match your exact make, model, year and specification before ordering.
