Piston Kit 86-04 KLF300 76.50, Forged Wossner 8597D050

Piston Kit 86-04 KLF300 76.50, Forged Wossner 8597D050. Find the product specifications and compatibility information below.

Product details

• Product: Piston Kit 86-04 KLF300 76.50, Forged Wossner 8597D050
• Part number: 56-W4671_050.WO
• Brand: Wossner
• High-strength forged piston construction
• Optimized heat transfer for improved combustion efficiency
• Elliptical design for even thrust load distribution
• Manufactured in Germany
• Bore Size: 76.50mm
• Actual Bore Diameter: 76.44mm
• Compression Ratio: OEM
• OEM Compression Ratio: 8.60:1
• Displacement: 290cc
• Stroke: 68.00mm
• Clearance: 0.06mm
• Dome Volume: +0.40cm³
• Compression Height: 26.50mm
• Cross-Reference OEM Part Numbers
• Lock P/N: CW18
• Pin P/N: WP031
• Ring Set P/N: 765XDS

Vehicle fitment

Applications listed in the supplier fitment data:

• KAWASAKI KLF BAYOU 300cc — 1986–1987
• KAWASAKI KLF BAYOU 300cc — 1989–2005
• KAWASAKI KLF BAYOU 300cc — 1988–2005
• KAWASAKI KEF 300cc — 1995–2003
• KAWASAKI KVF PRAIRIE 300cc — 1999–2003
• KAWASAKI KLF BAYOU 250cc — 1986–2005
• KAWASAKI KLF BAYOU 300cc — 1986–2003

Match your exact make, model, year and specification before ordering.
