Piston Kit Yfm YFB250 71.00, Wossner Forged 8659DA 92-01

Piston Kit Yfm YFB250 71.00, Wossner Forged 8659DA 92-01. Find the product specifications and compatibility information below.

Product details

• Product: Piston Kit Yfm YFB250 71.00, Wossner Forged 8659DA 92-01
• Part number: 56-W4675+000.WO
• Brand: Wossner
• High-strength forged piston construction
• Optimized heat transfer for improved combustion efficiency
• Elliptical design for even thrust load distribution
• Manufactured in Germany
• Bore Size: 71mm
• Actual Bore Diameter: 70.94mm
• Compression Ratio: OEM
• OEM Compression Ratio: 9.50:1
• Displacement: 229cc
• Stroke: 58.00mm
• Clearance: 0.06mm
• Dome Volume: -4.70cm³
• Compression Height: 23.80mm
• Cross-Reference OEM Part Numbers
• Lock P/N: CW16
• Pin P/N: WP041
• Ring Set P/N: 710XDS

Vehicle fitment

Applications listed in the supplier fitment data:

• YAMAHA YFM BRUIN 250cc — 2005–2006
• YAMAHA YFM BIG BEAR 250cc — 2007–2009
• YAMAHA YFM BEAR TRACKER 250cc — 1999–2004
• YAMAHA YFB TIMBERWOLF 250cc — 1992–1999
• YAMAHA YFB TIMBERWOLF 250cc — 1994–2000
• YAMAHA YFM TIMBERWOLF 250cc — 1990–2000
• YAMAHA YFB BEARTRACKER 250cc — 2000–2004

Match your exact make, model, year and specification before ordering.
