Piston Kit 00-02 YZF426 95.00, Forged Wossner 8525DB

Piston Kit 00-02 YZF426 95.00, Forged Wossner 8525DB. Find the product specifications and compatibility information below.

Product details

• Product: Piston Kit 00-02 YZF426 95.00, Forged Wossner 8525DB
• Part number: 56-W4693+00B.WO
• Brand: Wossner
• Forged construction for enhanced strength and durability
• Optimized heat transfer for improved performance
• Elliptical design for uniform bearing surface distribution
• Designed to match OEM compression ratios
• Bore Size: 95.01mm
• Actual Size: 94.97mm
• Displacement: 426cc
• Stroke: 60.10mm
• Piston Clearance: 0.04mm
• Compression Ratio: OEM (12.50:1)
• Dome Volume: -7.00cm³
• Compression Height: 24.10mm
• Piston Lock Part Number: CW19
• Piston Pin Part Number: WP037
• Ring Set Part Number: 950XDS
• Cross-Reference OEM Part Numbers
• Wossner Part Number: 8525DB

Vehicle fitment

Applications listed in the supplier fitment data:

• YAMAHA YZ F 426cc — 2000–2002
• YAMAHA WR F 426cc — 2001–2002
• YAMAHA YZF 426cc — 2000–2002
• YAMAHA WRF 426cc — 2001–2002
• YAMAHA YZF 426cc — 2000–2003
• YAMAHA WRF 426cc — 2000–2003

Match your exact make, model, year and specification before ordering.
