Piston Kit 98-01 YFM600 97.50, Forged Wossner 8501D250

Piston Kit 98-01 YFM600 97.50, Forged Wossner 8501D250. Find the product specifications and compatibility information below.

Product details

• Product: Piston Kit 98-01 YFM600 97.50, Forged Wossner 8501D250
• Part number: 56-W4797+250.WO
• Brand: Wossner
• Wossner 97.50mm forged piston kit is designed for strength and durability. Engineered for optimal heat transfer, it ensures efficient cooling of the combustion chamber. The elliptical design provides a uniform bearing surface, reducing localized pressure and distributing thrust loads evenly to prevent piston collapse. Manufactured in Germany for precision and reliability.
• Forged construction for enhanced strength and longevity
• Optimized heat transfer for improved engine performance
• Elliptical design prevents piston collapse and ensures even load distribution
• Manufactured in Germany for high-quality standards
• Bore Size: 97.50mm
• Actual Bore Diameter: 97.43mm
• Displacement: 595 cm³
• Stroke: 84.00mm
• Clearance: 0.07mm
• Wossner Compression Ratio: 10.70:1
• OEM Compression Ratio: 8.50:1
• Dome Volume: -0.50 cm³
• Compression Height: 28.00mm
• Lock Part Number: CW22
• Pin Part Number: WP009
• Ring Set Part Number: 975XSY
• Cross-Reference OEM Part Numbers
• Part No: 56-W4797+250.WO

Vehicle fitment

Applications listed in the supplier fitment data:

• YAMAHA XT 600cc — 1984–2004
• YAMAHA TT 600cc — 1984–2004
• YAMAHA XT E 600cc — 1984–2004
• YAMAHA TT R 600cc — 1984–2004
• YAMAHA XT 600cc — 1984–1996
• YAMAHA SRX 600cc — 1984–1996
• YAMAHA XTZ 600cc — 1984–2004

Match your exact make, model, year and specification before ordering.
