Piston Kit YFZ450/R/X 98.00, Wossner 8601D300 Forged Kit

Piston Kit YFZ450/R/X 98.00, Wossner 8601D300 Forged Kit. Find the product specifications and compatibility information below.

Product details

• Product: Piston Kit YFZ450/R/X 98.00, Wossner 8601D300 Forged Kit
• Part number: 56-W4865+300.WO
• Brand: Wossner
• Forged piston for high strength and durability
• Designed for optimal heat transfer to cylinder walls
• Elliptical design ensures even bearing surface during heat expansion
• Prevents localized pressure and piston collapse
• Manufactured in Germany
• Bore: 98.00 mm
• Actual Bore Diameter: 97.95 mm
• Display: 449 cm³
• Hub Stroke: 62.00 mm
• Clearance: 0.05 mm
• Compression Height: 25.00 mm
• Dome Volume: -7.40 cm³
• Compression Ratio: OEM (11.90:1)
• Theoretical Weight: Not specified
• Cross-Reference OEM Part Numbers
• Piston: 8601D300
• Lock: CW20
• Pin: WP038
• Ring Set: 980XSY
• Rod: P4029
• Part No.: 56-W4865+300.WO

Vehicle fitment

Applications listed in the supplier fitment data:

• KAWASAKI KX 125cc — 1982–1985
• YAMAHA YFZ X 450cc — 2009–2015

Match your exact make, model, year and specification before ordering.
