Piston Kit 04-08 KFX700 82mm, Wossner 8679DA Kawasaki 13001-1658

Piston Kit 04-08 KFX700 82mm, Wossner 8679DA Kawasaki 13001-1658. Find the product specifications and compatibility information below.

Product details

• Product: Piston Kit 04-08 KFX700 82mm, Wossner 8679DA Kawasaki 13001-1658
• Part number: 56-W4896.WO
• Brand: Wossner
• Forged piston designed for high-compression performance
• Engineered for efficient heat transfer to cylinder walls
• Elliptical profile ensures uniform pressure distribution during heat expansion
• Minimizes localized pressure and reduces the risk of piston collapse
• Manufactured in Germany
• Bore: 82.00 mm
• Actual Bore Diameter: 81.93 mm
• Display: 697 cm³
• Hub Stroke: 66.00 mm
• Clearance: 0.07 mm
• Compression Height: 26.30 mm
• Dome Volume: +3.20 cm³
• Wossner Compression Ratio: 11.30:1
• OEM Compression Ratio: 9.90:1
• Theoretical Weight: Not specified
• Cross-Reference OEM Part Numbers
• Piston: 8679DA
• Lock: CW20
• Pin: WP038
• Ring Set: 820XSY
• Part No.: 56-W4896.WO
• OEM Reference: 13001-1658, 4896M08200

Vehicle fitment

Applications listed in the supplier fitment data:

• SUZUKI LT V TWIN PEAKS F 700cc — 2004–2005
• KAWASAKI KVF PRAIRIE 700cc — 2004–2006
• KAWASAKI KFX 700cc — 2004–2010

Match your exact make, model, year and specification before ordering.
