Piston Kit 07-09 CRF150R 66 Hc, Wossner 8662DB 12.5:1 Comp

Piston Kit 07-09 CRF150R 66 Hc, Wossner 8662DB 12.5:1 Comp. Find the product specifications and compatibility information below.

Product details

• Product: Piston Kit 07-09 CRF150R 66 Hc, Wossner 8662DB 12.5:1 Comp
• Part number: 56-W4924+00B.WO
• Brand: Wossner
• Forged high-compression piston for strength and performance
• Designed for optimal heat transfer from combustion chamber to cylinder walls
• Elliptical shape provides a consistent bearing surface during thermal expansion
• Reduces the risk of piston collapse under localized pressure
• Manufactured in Germany
• Bore: 66.01 mm
• Actual Bore Diameter: 65.96 mm
• Display: 149 cm³
• Hub Stroke: 43.70 mm
• Clearance: 0.05 mm
• Compression Height: 20.60 mm
• Dome Volume: -1.80 cm³
• Wossner Compression Ratio: 12.50:1
• OEM Compression Ratio: 11.70:1
• Cross-Reference OEM Part Numbers
• Piston: 8662DB
• Lock: CW14
• Pin: WP058
• Ring Set: 660XKS
• Rod: P4024
• Part No.: 56-W4924+00B.WO

Vehicle fitment

Applications listed in the supplier fitment data:

• HONDA CRF R 150cc — 2007–2009
• HONDA CRF 150cc — 2007–2009

Match your exact make, model, year and specification before ordering.
