Piston Kit 08-12 RMZ450 96mm, Wossner 8716DC Suzuki Forged

Piston Kit 08-12 RMZ450 96mm, Wossner 8716DC Suzuki Forged. Find the product specifications and compatibility information below.

Product details

• Product: Piston Kit 08-12 RMZ450 96mm, Wossner 8716DC Suzuki Forged
• Part number: 56-W4953.C.WO
• Brand: Wossner
• Forged construction for enhanced strength and heat resistance
• Elliptical design for uniform expansion and load distribution
• Engineered for optimal combustion heat transfer
• Made in Germany
• Direct OEM replacement
• Easy to install; professional installation recommended if unsure
• Bore Size: 96.02mm
• Actual Bore: 95.98mm
• Displacement: 449cm³
• Stroke: 62.10mm
• Clearance: 0.04mm
• Dome Volume: -0.80cm³
• Compression Ratio: 12.20:1 (OEM)
• Compression Height: 23.10mm
• Cross-Reference OEM Part Numbers
• CW19 (Lock)
• WP037 (Pin)
• 960ADS-2 (Ring Set)
• MB83C072C (Main Bearing Right)
• MB830053-4 (Main Bearing Left)

Vehicle fitment

Applications listed in the supplier fitment data:

• SUZUKI RMX Z 450cc — 2010–2019
• SUZUKI RMX Z 450cc — 2010–2017
• SUZUKI RM Z 450cc — 2008–2012
• SUZUKI RMX Z 450cc — 2010–2018
• SUZUKI RMX Z 450cc — 2008–2012

Match your exact make, model, year and specification before ordering.
