Piston Kit 2014 YZF250 77.0 Hc, Forged Wossner 8894DC

Piston Kit 2014 YZF250 77.0 Hc, Forged Wossner 8894DC. Find the product specifications and compatibility information below.

Product details

• Product: Piston Kit 2014 YZF250 77.0 Hc, Forged Wossner 8894DC
• Part number: 56-W4962.C.WO
• Brand: Wossner
• Forged piston construction for high strength and reliability
• High compression design for increased performance
• Elliptical profile for balanced expansion and load distribution
• Engineered for effective combustion heat transfer
• Made in Germany
• Direct OEM replacement
• Easy to install; professional installation recommended if unsure
• Bore Size: 77.02mm
• Actual Piston Size: 76.97mm
• Displacement: 249cm³
• Stroke: 53.60mm
• Clearance: 0.05mm
• Dome Volume: -3.00cm³
• Wossner Compression Ratio: 13.70:1
• OEM Compression Ratio: 13.50:1
• Compression Height: 20.20mm
• Cross-Reference OEM Part Numbers
• 1SM-11631-01-00
• CW16 (Lock)
• WP087 (Pin)
• 770XAS-2 (Ring Set)

Vehicle fitment

Applications listed in the supplier fitment data:

• YAMAHA WRF 250cc — 2015–2017
• YAMAHA YZF 250cc — 2014–2015
• YAMAHA WRF 250cc — 2015

Match your exact make, model, year and specification before ordering.
