Piston Kit 87-89 KX250 67.40, Wossner 8129DA Kawasaki MX 13001-1246

Piston Kit 87-89 KX250 67.40, Wossner 8129DA Kawasaki MX 13001-1246. Find the product specifications and compatibility information below.

Product details

• Product: Piston Kit 87-89 KX250 67.40, Wossner 8129DA Kawasaki MX 13001-1246
• Part number: 56-W556+000.WO
• Brand: Wossner
• Forged piston for superior strength and durability
• Elliptical design allows for even bearing surface during thermal expansion
• Distributes thrust loads to reduce localised pressure and prevent piston collapse
• Engineered for efficient heat transfer from the combustion chamber to the cylinder walls
• Manufactured in Germany
• Bore: 67.40mm
• Actual diameter: 67.34mm
• Displacement: 249 cm³
• Stroke: 70.00mm
• Clearance: 0.06mm
• Compression height: 37.00mm
• Compression ratio: 2-stroke
• Cross-Reference OEM Part Numbers
• Piston Kit Part No.: 56-W556+000.WO
• Wossner Piston Kit No.: 8129DA
• Lock: CW18
• Pin: WP033
• Ring Set: RSB6740 x 2
• OEM Reference: 13001-1246
• Additional Reference: 556M06740

Vehicle fitment

Applications listed in the supplier fitment data:

• KAWASAKI KXF 250cc — 1987–1988
• KAWASAKI KX 250cc — 1987–1989

Match your exact make, model, year and specification before ordering.
