Piston Kit 86-88 YZ125 56.75, Wossner 8118D075 Yamaha MX

Piston Kit 86-88 YZ125 56.75, Wossner 8118D075 Yamaha MX. Find the product specifications and compatibility information below.

Product details

• Product: Piston Kit 86-88 YZ125 56.75, Wossner 8118D075 Yamaha MX
• Part number: 56-W559+075.WO
• Brand: Wossner
• Forged piston construction for enhanced strength and durability
• Elliptical design provides consistent bearing surface under thermal expansion
• Even distribution of thrust loads minimises localised stress and prevents piston collapse
• Optimised for efficient heat transfer from combustion chamber to cylinder walls
• Manufactured in Germany
• Bore: 56.75mm
• Actual diameter: 56.69mm
• Displacement: 123 cm³
• Stroke: 50.00mm
• Clearance: 0.06mm
• Compression height: 30.00mm
• Compression ratio: 2-stroke
• Cross-Reference OEM Part Numbers
• Piston Kit Part No.: 56-W559+075.WO
• Wossner Piston Kit No.: 8118D075
• Lock: CW16
• Pin: WP036
• Ring Set: RSB5675

Vehicle fitment

Applications listed in the supplier fitment data:

• YAMAHA YZ 125cc — 1986–1988

Match your exact make, model, year and specification before ordering.
