Piston Kit 87-90 LT500R 86.50, Wossner 8260D050 Suzuki ATV

Piston Kit 87-90 LT500R 86.50, Wossner 8260D050 Suzuki ATV. Find the product specifications and compatibility information below.

Product details

• Product: Piston Kit 87-90 LT500R 86.50, Wossner 8260D050 Suzuki ATV
• Part number: 56-W561+0.50.WO
• Brand: Wossner
• Forged construction for superior mechanical strength
• Optimised for efficient combustion heat transfer
• Elliptical design for uniform expansion and reduced localised stress
• Built specifically for high-performance 2-stroke engines
• Precision-manufactured in Germany
• Bore: 86.50 mm
• Actual Bore Diameter: 86.41 mm
• Compression Height: 45.00 mm
• Display Volume: 498 cm³
• Stroke: 86.00 mm
• Clearance: 0.09 mm
• Compression Ratio: 2-stroke (Wossner and OEM)
• Cross-Reference OEM Part Numbers
• Piston Kit Part No.: 8260D050
• Lock P/N: CW18
• Ring Set P/N: RSC8650 (x2)
• Alternate Part No.: 56-W561+0.50.WO

Vehicle fitment

Applications listed in the supplier fitment data:

• SUZUKI LT R 500cc — 1987–1990

Match your exact make, model, year and specification before ordering.
