Piston Kit 85-86 CR125 55.50, Wossner 8127D150 Honda MX

Piston Kit 85-86 CR125 55.50, Wossner 8127D150 Honda MX. Find the product specifications and compatibility information below.

Product details

• Product: Piston Kit 85-86 CR125 55.50, Wossner 8127D150 Honda MX
• Part number: 56-W563+150.WO
• Brand: Wossner
• High-strength forged piston for durability under performance conditions
• Enhanced thermal conductivity for improved heat transfer
• Elliptical design supports uniform thrust load distribution
• Minimises risk of piston collapse due to heat-induced expansion
• Precision-manufactured in Germany
• Bore Size: 55.50 mm
• Actual Bore Diameter: 55.44 mm
• Stroke: 54.00 mm
• Display Displacement: 124 cm³
• Clearance: 0.06 mm
• Compression Ratio (Wossner and OEM): 2-stroke
• Compression Height: 28.00 mm
• Cross-Reference OEM Part Numbers
• Piston Kit: 8127D150
• Lock: CW14
• Pin: WP025
• Ring Set: RSB5550 (Quantity: 2)
• Part No.: 56-W563+150.WO

Vehicle fitment

Applications listed in the supplier fitment data:

• HONDA CR 125cc — 1985–1986

Match your exact make, model, year and specification before ordering.
