Piston Kit 88-92 LT250 67.00, Wossner 8259DA Suzuki ATV

Piston Kit 88-92 LT250 67.00, Wossner 8259DA Suzuki ATV. Find the product specifications and compatibility information below.

Product details

• Product: Piston Kit 88-92 LT250 67.00, Wossner 8259DA Suzuki ATV
• Part number: 56-W571+0.00.WO
• Brand: Wossner
• Forged construction for enhanced strength and thermal reliability
• Efficient heat transfer from combustion chamber to cylinder wall
• Elliptical design provides uniform thrust load distribution under thermal expansion
• Minimises localised pressure points and risk of piston collapse
• Manufactured in Germany for precision and consistency
• Bore Size: 67.00 mm
• Actual Bore Diameter: 66.94 mm
• Stroke: 70.00 mm
• Display Displacement: 246 cm³
• Clearance: 0.06 mm
• Compression Ratio (Wossner and OEM): 2-stroke
• Compression Height: 37.20 mm
• Cross-Reference Wossner Part Numbers
• Piston Kit: 8259DA
• Lock: CW18
• Pin: WP033
• Ring Set: RSB6700 (Quantity: 2)
• Part No.: 56-W571+0.00.WO

Vehicle fitment

Applications listed in the supplier fitment data:

• SUZUKI LT QUADRACER 250cc — 1988–1992

Match your exact make, model, year and specification before ordering.
