Piston Kit 1987 LT250 67.50, Wossner 8258D050 Suzuki ATV

Piston Kit 1987 LT250 67.50, Wossner 8258D050 Suzuki ATV. Find the product specifications and compatibility information below.

Product details

• Product: Piston Kit 1987 LT250 67.50, Wossner 8258D050 Suzuki ATV
• Part number: 56-W577+0.50.WO
• Brand: Wossner
• Forged piston design for increased strength and longevity
• Engineered for efficient heat dissipation from the combustion chamber
• Elliptical profile ensures uniform bearing surface under heat expansion
• Developed for 2-stroke engine use
• Made in Germany
• Bore Size: 67.50mm (+0.50 oversize)
• Actual Bore: 67.44mm
• Compression Height: 37.20mm
• Clearance: 0.06mm
• Stroke: 70.00mm
• Displacement: 246 cm³
• Wossner Compression Ratio: 2-stroke
• OEM Compression Ratio: 2-stroke
• Cross-Reference OEM Part Numbers
• Wossner Piston: 8258D050
• Ring Set: RSB6750 (x2)
• Lock: CW18
• Pin: WP033
• Internal Reference: 56-W577+0.50.WO

Vehicle fitment

Applications listed in the supplier fitment data:

• SUZUKI LT 250cc — 1987

Match your exact make, model, year and specification before ordering.
