Piston Kit 1987 LT250 68.50, Wossner 8258D150 Suzuki ATV

Piston Kit 1987 LT250 68.50, Wossner 8258D150 Suzuki ATV. Find the product specifications and compatibility information below.

Product details

• Product: Piston Kit 1987 LT250 68.50, Wossner 8258D150 Suzuki ATV
• Part number: 56-W577+1.50.WO
• Brand: Wossner
• Wossner Forged Piston Kit 68.50mm Bore – Suzuki LT250 1987 (8258D150 +1.50)
• This Wossner forged piston kit with a +1.50mm oversize bore (actual 68.44mm) is specifically designed for the 1987 Suzuki LT250 ATV. Engineered for performance in 2-stroke engines, the piston’s forged construction ensures superior strength and durability. Its elliptical design enhances load distribution during thermal expansion, minimising stress concentrations and reducing the risk of piston failure. Precision manufactured in Germany for reliability under demanding conditions.
• Forged piston construction for high strength and durability
• Designed to improve heat dissipation from the combustion chamber
• Elliptically shaped to promote even thrust load distribution under thermal expansion
• Suitable for 2-stroke engine applications
• Made in Germany
• Bore Size: 68.50mm (+1.50 oversize)
• Actual Bore: 68.44mm
• Compression Height: 37.20mm
• Clearance: 0.06mm
• Stroke: 70.00mm
• Displacement: 246 cm³
• Wossner Compression Ratio: 2-stroke
• OEM Compression Ratio: 2-stroke
• Cross-Reference OEM Part Numbers
• Wossner Piston: 8258D150
• Ring Set: RSB6850 (x2)
• Lock: CW18
• Pin: WP033
• Internal Reference: 56-W577+1.50.WO
• Vehicle Fitments
• 1987 Suzuki LT250

Compatibility

No separate vehicle-fitment table record was supplied for this part. Check any application details, sizes and specifications above before ordering.
