Piston Kit 88-91 YZ250 68.50, Wossner 8134D050 Yamaha MX

Piston Kit 88-91 YZ250 68.50, Wossner 8134D050 Yamaha MX. Find the product specifications and compatibility information below.

Product details

• Product: Piston Kit 88-91 YZ250 68.50, Wossner 8134D050 Yamaha MX
• Part number: 56-W605+050.WO
• Brand: Wossner
• Forged construction for superior durability and strength
• Optimised design for combustion chamber heat transfer
• Elliptical shape promotes balanced load distribution under thermal expansion
• Precision-engineered in Germany
• Bore Size: 68.50 mm
• Piston Diameter: 68.44 mm
• Engine Displacement: 246 cm³
• Stroke: 68.00 mm
• Clearance: 0.06 mm
• Compression Height: 36.00 mm
• Compression Ratio: 2-stroke (Wossner and OEM)
• Cross-Reference Wossner Part Numbers
• Piston Kit: 8134D050
• Lock: CW18
• Pin: WP033
• Ring Set: RSB68500 x 2

Vehicle fitment

Applications listed in the supplier fitment data:

• YAMAHA YZ 250cc — 1988–1991
• YAMAHA WR 250cc — 1991
• YAMAHA WR 250cc — 1988–1991

Match your exact make, model, year and specification before ordering.
