Piston Kit 92-01 KX250 66.40 B, Wossner 8026DB Kawasaki MX

Piston Kit 92-01 KX250 66.40 B, Wossner 8026DB Kawasaki MX. Find the product specifications and compatibility information below.

Product details

• Product: Piston Kit 92-01 KX250 66.40 B, Wossner 8026DB Kawasaki MX
• Part number: 56-W617.B.WO
• Brand: Wossner
• Forged piston construction for durability under extreme conditions
• Efficient combustion chamber heat transfer to cylinder walls
• Elliptical design ensures even pressure distribution and minimises wear
• Manufactured in Germany to exacting standards
• Bore Size: 66.41 mm
• Piston Diameter: 66.35 mm
• Engine Displacement: 249 cm³
• Stroke: 72.00 mm
• Clearance: 0.06 mm
• Compression Height: 38.00 mm
• Compression Ratio: 2-stroke (Wossner and OEM)
• Cross-Reference Wossner Part Numbers
• Piston Kit: 8026DB
• Lock: CW18
• Pin: WP033
• Ring Set: RSB6640 x 2

Vehicle fitment

Applications listed in the supplier fitment data:

• KAWASAKI KX 250cc — 1992–2004
• KAWASAKI KX 250cc — 1992–2001

Match your exact make, model, year and specification before ordering.
