Piston Kit 89-95 RM250 69.00, Wossner 8022D200 Suzuki MX

Piston Kit 89-95 RM250 69.00, Wossner 8022D200 Suzuki MX. Find the product specifications and compatibility information below.

Product details

• Product: Piston Kit 89-95 RM250 69.00, Wossner 8022D200 Suzuki MX
• Part number: 56-W642_200.W0
• Brand: Wossner
• Forged construction for enhanced strength and resilience
• Optimised for efficient heat transfer to cylinder walls
• Elliptical design for uniform load distribution under thermal expansion
• Manufactured in Germany
• Bore: 69mm (actual size 68.94mm)
• Part Number: 56-W642_200.WO
• Lock Part Number: CW18
• Pin Part Number: WP033
• Ring Set Part Number: RSB6700 x 2
• Displacement: 246 cm³
• Stroke: 70.80mm
• Clearance: 0.06mm
• Wossner Compression Ratio: 2-stroke
• OEM Compression Ratio: 2-stroke
• Compression Height: 37.00mm
• Cross-Reference OEM Part Numbers
• Piston: 12110-28C11-0F0, 12110-29E20-0F0
• Ring, Piston: 12141-41600, 12141-41620
• Pin, Piston: 12151-28C00, 12151-37F00
• Circlip: 09381-18002

Vehicle fitment

Applications listed in the supplier fitment data:

• SUZUKI RMX 250cc — 1989–1999
• SUZUKI RM 250cc — 1989–1995

Match your exact make, model, year and specification before ordering.
